Automatic Nonwoven Cloth Perforation Slitting Machine

PPD-NCPS1100

Automatic nonwoven cloth perforation slitting machine is suit for slitting rewinding for spunlace nonwoven fabric,PP nonwoven
fabric,needle punched nonwoven fabric etc with auto perforation line.
This model can also work as normal nonwoven fabric slitting rewinding to cut the nonwoven fabric.
Machine works with touch screen and PLC program,the data setting is very simple.

Features:
1.Machine will be stopped automatically when it reaches the setting length.
2.Machine uses the pneumatic slitting system which is equipped with 10 sets of round slitting knives which can adjust the slitting freely.
3.The perforating distance is controlled by independent PLC and servo motor.
4.Use frequency convertor to adjust the running speed of the machine.
5.It has reasonable electronic wire layout and can be operated easily and safely.

Main Data:

Name:Automatic Nonwoven Cloth Perforation Slitting Machine

Model:PPD-NCPS1100

Mateiral spunlance nonwoven fabric,PP nonwoven

fabric,needle punched nonwoven fabric etc

Raw materials width:1100mm

Jumbo roll diameter:max1000mm

Jumbo roll weight:Max200kg

Suitable materials thickness:60-150gsm

Perforating distance:200-600mm(adjustable), inaccuracy≤2mm.

Jumbo roll paper core ID:3inch

Rewinding roll core size:3inch

Rewinding roll width:Max1100mm

Design speed:60-150m/min

Pneumatic Cutting Blade :10 pcs instaled on the machine

Voltage:380V,50Hz



Spunlace Nonwoven Fabric Slitting Machine , PP Nonwoven Fabric Slitting Machine, Needle Punched Nonwoven Slitting Machine
